MAIN FEATURES

Easy to assemble

All parts are re-attachable, connected by screws - no glue required.

3d print yourself

Most parts are 3D printed. You can print infinite spares, virtually for free. Compatible with most 3D printers.

Smooth workflow

Step-by-step user guide included. Prints are divided into logical groups, so you can assemble when you are printing parts for the next day.

It's not a poor toy

Off-road chassis, functional suspension and permanent 4WD with locked differentials – can handle any terrain.

Real gearbox

Real-like gearbox with a permanent gear ratio with high torque output.

Fun - at every stage!

Thoroughly tested – by kids. You will love both assembling and driving.

90

% of parts are 3d printable

15

ready to print setups

Legend comes – new 3d printable RC car "Landy 4x4"!

See the main features of this new model:











Easy to Assemble




To build the model you only need some basic tools such as a screwdriver, a sharp knife, soldering iron and most importantly - a good mood πŸ™‚











Image of the 3d printed scale radio controlled model Rancher 4x4 chassis detail view, including front differential and suspension.

3d print maximum, buy minimum




β€œDont buy parts – just print them, nearly all!” You print most parts starting with bodywork, complete chassis and even cardan joints and gearbox. Buy just motor, radio control electronics, tires and dampers – and you are prepared for ride.











Cheap and fast repairs




You broke something (and it was not easy :-)? Don't worry, in the meantime, you have a spare part re-printed. Then loose a few screws and exchange broken part. And – drive again, instantly!

Detailed bodywork




Rancher and Landy 4x4, they have all scale details based on a real car:

  • opening doors, hood, and trunk
  • body details such as door handles, wipers, side mirrors
  • complete interior parts (even floor mats!)
  • the body panels have gaps spaced like the actual car
Build Guide of the 3d printed gearbox from the 3d printed scale model Rancher 4x4.

Step-by-step User Guide




"Build when you print" – you get not only the ready-made print plates but also the time-effective print sequence, so you can continue assembling while you printing and do not need to wait for the part you need.

Build Guide is available online, include a complete bill of materials and links for online stores, when you can purchase non-printable parts.

Detailed Interior Parts




In addition to the dashboard and seats, the interior also features a folding armrest that hides the master switch of the model.

Real Gearbox




You'll also print a gearbox that resembles a real-world transmission. The gearbox includes printed wheels and shafts and reduces engine speed so even a small child can handle the model.

The high gear ratio provides high torque at the wheels and therefore the car can handle slope with 100% pitch.

Not a poor toy...




"Ride Everywhere" – the car not only has all-wheel drive but also permanently locked differentials, so it can get out of all the trouble.

β€œReal, long-travel link-based suspension” – suspension system is designed identically as the actual heavy-duty off-road cars. Centrally attached link bars ensures perfect rigidity of the chassis.

Filament friendly




We printed our models from PLA and its strong enough – even for outdoor riding. You can use ABS or CPE on some gears parts for even greater durability.Β You'll need roughly 2.5 kg of a filament to print the complete 4x4 model.

The 3d print data




We have prepared the data for your 3D printer in two ways – both the finished gcodes and the Prusa Slic3r slicer-compatible print plates are available for the well known 3d printer "Prusa i3 MK2 / 3".

For other printers with a common 20x20 cm print plate size, print plates are prepared in .stl format that is compatible with any slicing software.

Last but not least, individual parts for individual prints in .stl format are also available.

Image of 3d printed wheel rims with tyres of the 3d printed scale model Rancher 4x4.

What you need next to the printed parts?




Just buy set of specific screws (M2, M3 metric size), set of rubber tires, dampers with springs and RC electronics (transmitter, receiver, speed controller, steering servo, motor, battery). We provide a list of these in our user guide.

Drawing of 3d printed scale model Rancher 4x4

Technical Parameters




Our RC car models are in 1:8 scale, around 50 cm (20 inches) long, about 3.2 kg weight. They are ready to be radio-controlled, 2-way RC system is required (steering + speed control). The model uses standard electronic components available in online stores, including motor, servo, Li-Poly battery.
